SKF TUWK 20 LTA Bearing

SKF Bearing Professional After-sales Guarantee Easy And Secure Payment TUWK 20 LTA Transparent And Fair Price On Time Delivery

SKF TUWK 20 LTA Bearing Description

We supply various of SKF TUWK 20 LTA bearings. bearings is purity material and high precision , the varieties of SKF bearings is up to thousands of species .SKF TUWK 20 LTA bearings is known as ” the food of machinery industry” and widely used in different environment and mechanical.The purpose of SKF TUWK 20 LTA bearings is the operation and control. In order to ensure the smooth operation and normally rotation,SKF TUWK 20 LTA bearings inquire deeply into the running of the machine and friction phenomenon .SKF TUWK 20 LTA bearings is widely used in automobile, motor, gear, injection molding machines, machine tools, mining machinery, engineering machinery, motorcycles, office equipment, paper making machinery, pumps and compressors, wind power generator and so on.The shipment of SKF TUWK 20 LTA bearings will be arranged timely for we have a large stock of SKF TUWK 20 LTA bearings in HongKong.

SKF TUWK 20 LTA Bearing Specification

Bearing number : TUWK 20 LTA

Size (mm) : 20×27.5×12

Brand : The brand you need

Bore Diameter (mm) : 20

Outer Diameter (mm) : 27,5

Width (mm) : 12

Bearing dimensions and specification in ALIER catalogue:

d – 20 mm

A – 27.5 mm

A₁ – 12 mm

A₂ – 24.5 mm

A₅ – 20.3 mm

B – 31 mm

H – 89 mm

H₁ – 76 mm

H₂ – 36 mm

L – 99 mm

L₁ – 64 mm

L₃ – 46 mm

G – M16

G₁ – 21 mm

s₁ – 18.3 mm

Basic dynamic load rating – C – 12.7 kN

Basic static load rating – C₀ – 6.6 kN

Fatigue load limit – P_u – 0.28 kN

Limiting speed with shaft tolerance h6 – 5000 r/min

Mass bearing unit – 0.34 kg

Grub (set) screw – G₂ – M6x0.75

Hexagonal key size for grub screw – H – 3 mm

Recommended tightening torque for grub screw – 4 N??m

Housing – TUWK 504 L

Bearing – YAR 204-2RF/VE495

End cover – ECL 204
