SKF SYNT 80 FTS Bearing

SKF Bearing Professional After-sales Guarantee Easy And Secure Payment SYNT 80 FTS Transparent And Fair Price On Time Delivery

SKF SYNT 80 FTS Bearing Description

We supply various of SKF SYNT 80 FTS bearings. bearings is purity material and high precision , the varieties of SKF bearings is up to thousands of species .SKF SYNT 80 FTS bearings is known as ” the food of machinery industry” and widely used in different environment and mechanical.The purpose of SKF SYNT 80 FTS bearings is the operation and control. In order to ensure the smooth operation and normally rotation,SKF SYNT 80 FTS bearings inquire deeply into the running of the machine and friction phenomenon .SKF SYNT 80 FTS bearings is widely used in automobile, motor, gear, injection molding machines, machine tools, mining machinery, engineering machinery, motorcycles, office equipment, paper making machinery, pumps and compressors, wind power generator and so on.The shipment of SKF SYNT 80 FTS bearings will be arranged timely for we have a large stock of SKF SYNT 80 FTS bearings in HongKong.

SKF SYNT 80 FTS Bearing Specification

Bearing number : SYNT 80 FTS

Size (mm) : 80x100x72

Brand : The brand you need

Bore Diameter (mm) : 80

Outer Diameter (mm) : 100

Width (mm) : 72

Bearing dimensions and specification in ALIER catalogue:

d_a – 80 mm

A – 100 mm

B – 72 mm

H – 191 mm

H₁ – 100 mm

H₂ – 35 mm

J – 290 mm

L – 345 mm

H – 28 mm

N₁ – 22 mm

J₆ – 320 mm

J₇ – 37.5 mm

N₄ – max. – 8 mm

Basic dynamic load rating – C – 236 kN

Basic static load rating – C₀ – 270 kN

Fatigue load limit – P_u – 29 kN

Limiting speed – 3100 r/min

Calculation factor – e – 0.22

Calculation factor – Y₁ – 3

Calculation factor – Y₂ – 4.6

Diameter – d_m – 110 mm

Basic Designation bearing – 22216 E

P_a – 25 kN

P_0° – 430 kN

P_55° – 480 kN

P_90° – 290 kN

P_120° – 205 kN

P_150° – 190 kN

P_180° – 240 kN

Mass bearing unit – 20 kg

Diameter – G – 20 mm
