SKF GEP360FS Bearing

SKF Bearing Professional After-sales Guarantee Easy And Secure Payment GEP360FS Transparent And Fair Price On Time Delivery

SKF GEP360FS Bearing Description

We supply various of SKF GEP360FS bearings. bearings is purity material and high precision , the varieties of SKF bearings is up to thousands of species .SKF GEP360FS bearings is known as ” the food of machinery industry” and widely used in different environment and mechanical.The purpose of SKF GEP360FS bearings is the operation and control. In order to ensure the smooth operation and normally rotation,SKF GEP360FS bearings inquire deeply into the running of the machine and friction phenomenon .SKF GEP360FS bearings is widely used in automobile, motor, gear, injection molding machines, machine tools, mining machinery, engineering machinery, motorcycles, office equipment, paper making machinery, pumps and compressors, wind power generator and so on.The shipment of SKF GEP360FS bearings will be arranged timely for we have a large stock of SKF GEP360FS bearings in HongKong.

SKF GEP360FS Bearing Specification

Bearing number : GEP360FS

Size (mm) : 360x520x258

Brand : The brand you need

Bore Diameter (mm) : 360

Outer Diameter (mm) : 520

Width (mm) : 258

Bearing dimensions and specification in ALIER catalogue:

d – 360 mm

D – 520 mm

B – 258 mm

C – 243 mm

b – 21 mm

b1 – 21 mm

dk – 474 mm

r1 min. – 1,1 mm

r2 min. – 4 mm

M – 8 mm

da min. – 377 mm

da max – 397 mm

Da min – 441 mm

Da max. – 490 mm

ra max. – 1 mm

rb max. – 4 mm

Angle – 2 °

Weight – 200 Kg

Basic dynamic load rating (C) – 8150 kN

Basic static load rating (C0) – 12200 kN
