SKF GEC320FBAS Bearing

SKF Bearing Professional After-sales Guarantee Easy And Secure Payment GEC320FBAS Transparent And Fair Price On Time Delivery

SKF GEC320FBAS Bearing Description

We supply various of SKF GEC320FBAS bearings. bearings is purity material and high precision , the varieties of SKF bearings is up to thousands of species .SKF GEC320FBAS bearings is known as ” the food of machinery industry” and widely used in different environment and mechanical.The purpose of SKF GEC320FBAS bearings is the operation and control. In order to ensure the smooth operation and normally rotation,SKF GEC320FBAS bearings inquire deeply into the running of the machine and friction phenomenon .SKF GEC320FBAS bearings is widely used in automobile, motor, gear, injection molding machines, machine tools, mining machinery, engineering machinery, motorcycles, office equipment, paper making machinery, pumps and compressors, wind power generator and so on.The shipment of SKF GEC320FBAS bearings will be arranged timely for we have a large stock of SKF GEC320FBAS bearings in HongKong.

SKF GEC320FBAS Bearing Specification

Bearing number : GEC320FBAS

Size (mm) : 320x440x160

Brand : The brand you need

Bore Diameter (mm) : 320

Outer Diameter (mm) : 440

Width (mm) : 160

Bearing dimensions and specification in ALIER catalogue:

d – 320 mm

D – 440 mm

B – 160 mm

C – 135 mm

b – 21 mm

b1 – 21 mm

dk – 380 mm

r1 min. – 1,1 mm

r2 min. – 3 mm

M – 8 mm

da min. – 328 mm

da max – 344 mm

Da min – 370 mm

Da max. – 426 mm

ra max. – 1 mm

rb max. – 3 mm

Angle – 4 °

Weight – 69 Kg

Basic dynamic load rating (C) – 3000 kN

Basic static load rating (C0) – 4500 kN

Tags :  ALIER , 320x440x160
