SKF BSA 212 C Bearing

SKF Bearing Professional After-sales Guarantee Easy And Secure Payment BSA 212 C Transparent And Fair Price On Time Delivery

SKF BSA 212 C Bearing Description

We supply various of SKF BSA 212 C bearings. bearings is purity material and high precision , the varieties of SKF bearings is up to thousands of species .SKF BSA 212 C bearings is known as ” the food of machinery industry” and widely used in different environment and mechanical.The purpose of SKF BSA 212 C bearings is the operation and control. In order to ensure the smooth operation and normally rotation,SKF BSA 212 C bearings inquire deeply into the running of the machine and friction phenomenon .SKF BSA 212 C bearings is widely used in automobile, motor, gear, injection molding machines, machine tools, mining machinery, engineering machinery, motorcycles, office equipment, paper making machinery, pumps and compressors, wind power generator and so on.The shipment of SKF BSA 212 C bearings will be arranged timely for we have a large stock of SKF BSA 212 C bearings in HongKong.

SKF BSA 212 C Bearing Specification

Bearing number : BSA 212 C

Size (mm) : 60x110x22

Brand : The brand you need

Bore Diameter (mm) : 60

Outer Diameter (mm) : 110

Width (mm) : 22

Bearing dimensions and specification in ALIER catalogue:

d – 60 mm

D – 110 mm

H – 22 mm

d₁ – 76.9 mm

d₂ – 87 mm

D₁ – 87.1 mm

D₂ – 97.75 mm

r_1,2 – min. – 1.1 mm

a – 93 mm

d_a – min. – 71 mm

d_b – min. – 71 mm

D_a – max. – 102 mm

D_b – max. – 102 mm

r_a – max. – 1.5 mm

Basic dynamic load rating – C – 69.5 kN

Basic static load rating – C₀ – 216 kN

Fatigue load limit – P_u – 8 kN

Limiting speed for grease lubrication – 5000 r/min

Limiting speed for oil lubrication – 6000 mm/min

Preload class A – 6050 N

Preload class B – 12100 N

Frictional moment, Preload class A – 0.54 N??m

Frictional moment, Preload class B – 1.05 N??m

Static Axial rigidity, Preload class A – 1640 N/micron

Static Axial rigidity, Preload class B – 2080 N/micron

Max. axial load – F_a – max. 65 kN

G_ref – 8.5 cm3

Mass bearing – 0.95 kg
