SKF 53322M+U322 Bearing

SKF Bearing Professional After-sales Guarantee Easy And Secure Payment 53322M+U322 Transparent And Fair Price On Time Delivery

SKF 53322M+U322 Bearing Description

We supply various of SKF 53322M+U322 bearings. bearings is purity material and high precision , the varieties of SKF bearings is up to thousands of species .SKF 53322M+U322 bearings is known as ” the food of machinery industry” and widely used in different environment and mechanical.The purpose of SKF 53322M+U322 bearings is the operation and control. In order to ensure the smooth operation and normally rotation,SKF 53322M+U322 bearings inquire deeply into the running of the machine and friction phenomenon .SKF 53322M+U322 bearings is widely used in automobile, motor, gear, injection molding machines, machine tools, mining machinery, engineering machinery, motorcycles, office equipment, paper making machinery, pumps and compressors, wind power generator and so on.The shipment of SKF 53322M+U322 bearings will be arranged timely for we have a large stock of SKF 53322M+U322 bearings in HongKong.

SKF 53322M+U322 Bearing Specification

Bearing number : 53322M+U322

Size (mm) : 110x190x67.2

Brand : The brand you need

Bore Diameter (mm) : 110

Outer Diameter (mm) : 190

Width (mm) : 67,2

Bearing dimensions and specification in ALIER catalogue:

d – 110 mm

D – 190 mm

H – 67,2 mm

d1 – 187 mm

r1 min. – 2 mm

r2 min. – 2 mm

s – 51 mm

C – 20 mm

D1 – 113 mm

D2 – 150 mm

D3 – 195 mm

H1 – 72 mm

R – 140 mm

da min. – 140 mm

Da max. – 158 mm

rb max. – 1 mm

Weight – 9,1 Kg

Basic dynamic load rating (C) – 281 kN

Basic static load rating (C0) – 815 kN

Fatigue load limit (Pu) – 24,5

Reference speed – 1100 r/min

Limiting speed – 1600 r/min

Minimum load factor (A) – 3,2
