SKF 29438 E Bearing

SKF Bearing Professional After-sales Guarantee Easy And Secure Payment 29438 E Transparent And Fair Price On Time Delivery

SKF 29438 E Bearing Description

We supply various of SKF 29438 E bearings. bearings is purity material and high precision , the varieties of SKF bearings is up to thousands of species .SKF 29438 E bearings is known as ” the food of machinery industry” and widely used in different environment and mechanical.The purpose of SKF 29438 E bearings is the operation and control. In order to ensure the smooth operation and normally rotation,SKF 29438 E bearings inquire deeply into the running of the machine and friction phenomenon .SKF 29438 E bearings is widely used in automobile, motor, gear, injection molding machines, machine tools, mining machinery, engineering machinery, motorcycles, office equipment, paper making machinery, pumps and compressors, wind power generator and so on.The shipment of SKF 29438 E bearings will be arranged timely for we have a large stock of SKF 29438 E bearings in HongKong.

SKF 29438 E Bearing Specification

Bearing number : 29438 E

Size (mm) : 190x380x115

Brand : The brand you need

Bore Diameter (mm) : 190

Outer Diameter (mm) : 380

Width (mm) : 115

Bearing dimensions and specification in ALIER catalogue:

d – 190 mm

D – 380 mm

H – 115 mm

d₁ – – 332 mm

D₁ – – 265 mm

B – 73 mm

B₁ – 101 mm

C – 55.5 mm

s – 117 mm

r_1,2 – min. – 5 mm

d_a – min. – 280 mm

d_b1 – max. – 207 mm

d_b2 – max. – 223 mm

D_a – max. – 321 mm

r_a – max. – 4 mm

Basic dynamic load rating – C – 2850 kN

Basic static load rating – C₀ – 8000 kN

Fatigue load limit – P_u – 765 kN

Reference speed – 950 r/min

Limiting speed – 1700 r/min

Factor min. axial load – A – 6.1

Mass bearing – 60.5 kg
